EAN-13 Specifications

07 EAN 13 Standard 768x502

The following provides a guideline for the size (EAN-13) you should print the barcode on your product. This is very important if you require barcode verification. It is also a good guide for ensuring that your barcode scans correctly. If at all possible you should keep your barcode size within these standards. If you go outside these standards, you barcodes might be accepted by some retailers and rejected by others.

EAN-13 Dimensions with 100% Magnification:

ean13 dimensions 300x246

Barcode width = 31.35mm

Left quiet zone (left blank margin) = 3.63mm

Right quiet zone (right blank margin) = 2.31mm

Total barcode width (including quiet zones) = 37.29mm

Barcode height (excluding the number) = 22.85mm

Barcode height (including the number) = 25.93mm

Allowable Magnification Range:

The specified magnification range for an EAN-13 Bar Code Symbol being scanned at retail point of sale is 80% – 200% (X-dimension 0.26mm-0.66mm). An acceptable minimum magnification of 75% (X-dimension 0.25mm) is applicable only to on demand (e.g. thermal) print processes. In this case, the bar height should never be truncated below the minimum needed height for an 80% magnification barcode symbol.

Where an item may also be scanned in a General Distribution Scanning environment (automated scanning), the acceptable magnification range for a General Distribution Environment is 150% to 200% (X-dimension 0.50mm – 0.66mm).



Human Readable Interpretation

The Human Readable Interpretation should be printed beneath the bar code symbol.

The recommended typeface for the Human Readable Interpretation is OCR-B at a height of 2.75mm at nominal size (100% magnification, X-dimension 0.33mm). This typeface is a recommendation only and alternative type fonts and character sizes are acceptable provided the digits are clearly legible.

Dimensions (All measurements in millimetres)

Magnification X-dimension Width Bar height Left Quiet Zone Right Quiet Zone
0.80 0.26 25.08 18.28 2.90 1.85
0.85 0.28 26.65 19.42 3.09 1.96
0.90 0.30 28.22 20.57 3.27 2.08
0.95 0.31 29.78 21.71 3.45 2.19
1.00 0.33 31.35 22.85 3.63 2.31
1.05 0.35 32.92 23.99 3.81 2.43
1.10 0.36 34.49 25.14 3.99 2.54
1.15 0.38 36.05 26.28 4.17 2.66
1.20 0.40 37.62 27.42 4.36 2.77
1.25 0.41 39.19 28.56 4.54 2.89
1.30 0.43 40.76 29.71 4.72 3.00
1.35 0.45 42.32 30.85 4.90 3.12
1.40 0.46 43.89 31.99 5.08 3.23
1.45 0.48 45.46 33.13 5.26 3.35
1.50 0.50 47.03 34.28 5.45 3.47
1.55 0.51 48.59 35.42 5.63 3.58
1.60 0.53 50.16 36.56 5.81 3.70
1.65 0.54 51.73 37.70 5.99 3.81
1.70 0.56 53.30 38.85 6.17 3.93
1.75 0.58 54.86 39.99 6.35 4.04
1.80 0.59 56.43 41.13 6.53 4.16
1.85 0.61 58.00 42.27 6.72 4.27
1.90 0.63 59.57 43.42 6.90 4.39
1.95 0.64 61.13 44.56 7.08 4.50
2.00 0.66 62.70 45.70 7.26 4.62







































Terms:

– Bar Width = width of barcode symbol excluding Quiet Zones

– Bar Height = height of bar excluding guard bar patterns

– Quiet Zone = Area of white space on either side of the bars

It is a good idea to allow for more quiet zone space than is strictly required in case of ink spread or printing inaccuracies
